IR HiRel功率IGBT –絕緣柵雙極晶體管

發布時間：2021-01-06 17:10:30     瀏覽：2764

IR HiRel不同分立器件具有不同的電壓和電流電平，功率模塊甚至堆棧解決方案。

IR HiRel的IGBT產品選擇提供了多種不同的設備。IR-HiRel產品廣泛應用于汽車、牽引、工業和消費系統。IR-HiRel的解決方案在正向和阻塞狀態下具有非常低的功耗，只需要較低的驅動功率，并且具有較高的效率。IGBT可承受高達6.5 kV的電壓，并在2 kHz至50 kHz的開關頻率下工作。

由于廣泛的技術產品組合，工業和功率控制IGBT設計具有優異的電流能力和更高的脈沖負載能力，以實現超低功耗。

IR HiRel提供多種IGBT芯片組合。這些IGBT芯片封裝在離散的塑料封裝中，可以作為“單個IGBT”使用，并與續流二極管一起封裝。該設備適用于以下應用：通用變頻器、太陽能逆變器、UPS、感應加熱、主要家用電器、焊接和開關電源。分立IGBT的優點是電流密度高、功耗低，效率高、散熱面積小，從而降低了系統的整體成本。

電源模塊通常由IGBT和電源模塊組成。即用堆棧配置為滿足最高功率應用的要求。這些堆棧是建立在IGBT功率模塊或光盤，取決于應用領域。英飛凌的產品包括整流器、制動斬波器和逆變器組件，以及功率最高的堆疊組件，從數百瓦到數兆瓦不等。通用驅動器、伺服裝置和可再生能源應用受益于這些高度可靠產品的優異性能、效率和壽命。

HybridPACK?系列﹣因為具有汽車認證的特殊產品系列可用于支持設計師的設計工作﹣電動汽車。英飛凌通過提供各種獨立的IGBT功率半導體進一步支持汽車工業，這些半導體符合aecq101的要求。

深圳市立維創展科技有限公司，優勢渠道供貨IR高可靠性系列產品，歡迎各界前來咨詢。

詳情了解IR HiRel請點擊：/brand/65.html

或聯系我們的銷售工程師：0755-83642657   QQ: 2295048674

IR HiRel.jpg

25 out of 25 boards

Board

Family

Description

MA400E12



EVAL-M3-TS6-665PN

Buy online

Gate Driver, IGBT Discrete

Evaluation Board with half-bridge driver (IRS2890DS), single low-side driver (IRS44273L) and IGBT H5 (IKB20N65EH5).

IRS2890DS

IKB20N65EH5

IKD06N65ET6

IRS44273L

EVAL-IGBT-1200V-247

Buy online

Gate Driver, IGBT Discrete

Evaluation Board as adaptable double pulse tester for IGBTs in TO-247 4pin package with the 1200 V isolated gate driver 1EDI6012AH

1EDI60I12AH

EVAL-1EDI60I12AF

Buy online

Gate Driver, IGBT Discrete

Evaluation board with two single-channel galvanic-isolated gate driver ICs - 1EDI60I12AF and two IGBTs - IKW50N65F5. The major features of the evaluation board are: short circuit protection, current measurement, under voltage lock-out, bootstrap functionality for the high side gate driver, and possibility of separating input and output side.

1EDI60I12AF

IKW50N65F5

HYBRID KIT1+

Gate Driver, IGBT Modules

Main inverter Evaluation Kit including HybridPACK? 1, gate driver board, DC link capacitor, refrence alu cooler and logic board

1ED020I12FA2

FS400R07A1E3

EASYKIT DCDC

Gate Driver, IGBT Modules

Evaluation Kit for the F4-50R07W1H3_B11A EasyPACK 1B Automotive Power Modules.

F4-50R07W1H3_B11A

HYBRID KIT DSC

Gate Driver, IGBT Modules

Main inverter evaluation kit for the HybridPACK? DSC S1

1EDI2010AS

FF400R07A01E3_S6

MA070E17

Gate Driver, IGBT Modules

Evaluation Adapter board with booster stage for 62mm modules up to 1700V.

MA070E12

Gate Driver, IGBT Modules

Evaluation Adapter board with booster stage for 62mm modules up to 1200V.

MA401E17

Gate Driver, IGBT Modules

Evaluation Adapter Board with booster stage for IHM IGBT Modules up to 1700V (140mm x 190mm).

MA400E17

Gate Driver, IGBT Modules

Evaluation Adapter board with booster stage for IHM modules up to 1700V (130mm x 140mm).

MA401E12

Gate Driver, IGBT Modules

Evaluation Adapter Board with booster stage for IHM IGBT Modules up to 1200V (140mm x 190mm).

2ED250E12-F

Gate Driver, IGBT Modules

Evaluation Driver Board for PrimePACK? Modules up to 1200V using a coreless transformer single-channel driver (replaced by 1ED020I12-F2).

1ED020I12-F2

MA200E12

Gate Driver, IGBT Modules

Evaluation Adapter board with booster stage for 1200V EconoDUAL? 3 modules.

2ED300C17-S

2ED300C17-ST

MA200E17

Gate Driver, IGBT Modules

Evaluation Adapter board with booster stage for 1700V EconoDUAL? 3 modules.

6ED100E12-F2

Gate Driver, IGBT Modules

Evaluation Driver board for EconoPACK?+ IGBT modules, using a coreless transformer single-channel driver (replaced by 1ED020I12-F2).

1ED020I12-F2

MA300E12

Gate Driver, IGBT Modules

Evaluation Adapter board containing a booster stage for driving 1200V PrimePACK? in single or parallel configuration.

2ED300C17-S

2ED300C17-ST

MA300E17

Gate Driver, IGBT Modules

Evaluation Adapter board containing a booster stage for driving 1700V PrimePACK? in single or parallel configuration.

2ED100E12-F2

Gate Driver, IGBT Modules

Evaluation Driver Board for EconoDUAL?3 Modules using a coreless transformer single-channel driver (replaced by the EiceDRIVER? 1ED020I12-F2)

1ED020I12-F2

EVAL-M1-6ED2230-B1

Buy online

Gate Driver, IGBT Modules

Evaluation Board for 1200 V Three-Phase SOI Gate Driver with Integrated Bootstrap Diode and OCP and EasyPIM? 1200V Easy1B three-phase module for motor-drive application

6ED2230S12T

FP15R12W1T4

KIT HYBRIDPACK DSC S2

Gate Driver, IGBT Modules, Microcontroller

Main inverter evaluation kit for the HybridPACK? DSC S2 (FF450R08A03P2), gate driver board, DC link capacitor, reference alu cooler and logic board.

1EDI2010AS

FF450R08A03P2

EVAL-IGBT-650V-TO247-4

Buy online

IGBT Discrete, Gate Driver

Adaptable double pulse tester for IGBTs in TO-247 4pin package

HYBRID KIT DRIVE 1200V

IGBT Modules

Traction inverter Evaluation Kit including HybridPACK? Drive 1200V, gate driver board, DC link capacitor, cooler and logic board.

HYBRID KIT DRIVE SENSE

IGBT Modules

Main inverter Evaluation Kit including HybridPACK? Drive, gate driver board, DC link capacitor, reference alu cooler, logic board and LEM current sensor HAH3DR 800-S07

1EDI2010AS

FS820R08A6P2LB

HYBRID KIT DRIVE

IGBT Modules

Main inverter Evaluation Kit including HybridPACK? Drive, gate driver board, DC link capacitor, reference alu cooler and logic board.

FS820R08A6P2B

1EDI2010AS
